SOLAR PARABOLIC COOKER

SOLAR PARABOLIC COOKER SK 2.7

SOLAR PARABOLIC COOKER SK 2.7

Best for fast cooking. Solar parabolic cooker dia 1.4 mtr. Designed for commercial and domestic use. Heavy and sturdy construction to with and the heavy wind speed. High quality reflective material. Castor wheel arrangement for easy moving. Capacity 15 people at time. Bottom of the cooker coated with high thermal absorbing coating. Manual tracking. Export quality workmanship. Powder coated support structure attractive look. Its performance is better from simple solar box cooker. Ideal design for any region of the world. Cooking at higher temperature. Attention required.

Application: It can be used for backing, boiling, cooking and frying also. This can be used for cooking in domestic as well as industrial canteens, hostels, hotels, restaurants, ashram, dharma shala, orphanage, old age etc. Commercial places

    FEATURES

  • Sk 12 –solar cooker uses parabolic reflector made of thin, hard aluminum sheets with protected, high reflecting surface mounted at a rigid basket structure.
  • Reflector with short focal distance for safety reasons, long tracking intervals and high efficiency.
  • Cooking pot in a standard 12–liters pot of black enameled steel with a diameter of 28 cm.
  • Tracking is done by moving the whole cooker (azimuth) and by turning the reflector around the horizontal axis (elevation), adjustment of the reflector to the sun by use of a shadow indicator.

    TECHNICAL DETAILS

  • Material of reflector 0.4 mm : Aluminum sheets of thickness
  • Reflectivity : 75% minimum
  • Size of focal spot : 340 mm approximate minimum
  • Focal length : 400 mm minimum
  • Dimension& shape: 2.3 meter diameter community
  • Surface area of reflector : 4.79 sqm
  • Aperture area of reflector : 4.15 sqm
  • Tracking of sun : manual
  • Cooking vessel : Pressure cooker (isi) of 15 liter capacity, powder coated black from bottom.
  • Other accessories: cap, hand gloves & goggles of good quality.
  • Power availability at cooking pot : about 2.5 kw (with over 600 w/sq.m. direct/750 w/sq.m. Total solar insulation available on reflector )
  • Thermal efficiency: Over 40%
  • Life metallic structure : 20 years. It shall be able to withstand high wind speeds.
  • Reflecting mirrors : Minimum 5 year

MARKETING AREA

National
Jammu & Kashmir, Himachal Pardesh, Punjab, Haryana, Uttrakhand, Delhi, Uttar Pardesh,Madhya Pardesh, Bihar, West Bangal , Odisha, Assam, Nagaland , Arunachal Pardesh, Mahaarastra, Chhattishgarh, Goa, Gujrat, Jharkhand, Karnataka, Kerala, Manipur,Meghalaya, Mizoram, Sikkim,Telangana, Tripura, Tamilnadu,Rajasthan.
International
Afganisthan, Nigeria, Austria, Qatar, Cambodia.
